Maintenance Pendulum frame - adjusting the float springs The pendulum frame is held horizontal with the springs (4). The position of the front attachment is adjusted using spring tension. Proceed as follows:
Z 4
– Open the hood and secure – see Hood, page 9.50. – Release nuts (5).
5
– Tension springs (4) evenly with bolts (6) to dimension (Z).
4 46
Basic setting: Dimension (Z) = 82.5 mm ± 2.5 mm – Tighten nuts (5). – Check setting with front attachment fitted. – Fit front attachment completely. – Raise front attachment.
6
– Open lock. The front attachment must be horizontal. – If necessary, correct the setting until the front attachment is horizontal. – Close hood – see Hood, page 9.50. 47
