Maintenance – Open the hood (1) and secure – see Hood, page 9.50.
1
(Fig. 43)
43
– Loosen nut (3). – Screw in or back off spring guide (4) to dimension (Z).
2 3
– Tension spring (2) with nut (3). – Check dimension (Z). – Repeat procedure if necessary. – Tighten nut (2). Dimension Z = 47 mm (Fig. 44)
Z
4 44
Checking V-belts Check the V-belts of the mower drive regularly for wear, breakage and other damage and replace if necessary. NOTE! Replace V-belts in sets only.
00 0294 017 2 - BA DIRECT DISC 610 / 520 Comfort
9.20
