Maintenance Tensioning drive chain with chain tensioner The chain tensioner (10) is only fitted on front attachments with additional equipment “hydraulic paddle adjustment”.
with additional equipment “Hydraulic paddle adjustment”
10
(Fig. 40)
DANGER! Danger of crushing at pinch points on pretensioned components. Serious injuries. 40
– Never reach in between pretensioned components. – Use suitable aids to secure pretensioned components or relieve them. – Follow the instructions.
– Open left side panelling – see Side panelling, page 9.50. – If necessary, attach spring (12) on the bracket (11).
with additional equipment “Hydraulic paddle adjustment”
(Fig. 41)
11
12
41
– Fully screw nut (14) onto the eye bolt (13).
with additional equipment “Hydraulic paddle adjustment”
– Attach eye bolt (13). 12
– Tension spring (12) with nut (15). – Tighten nut (15). (Fig. 42)
13 14 15 42
00 0294 017 2 - BA DIRECT DISC 610 / 520 Comfort
9.18
