Maintenance The feed drums are fastened to one flange each. The bolts (1) for securing the feed drums must be tightened as specified. 1
2
– Fit bolts (1) and nut (2) with liquid screw fastener. For example Loctite 243 (50 ml) Order no. 000 666 285 1 – Tighten bolts (1) and nut (2) with torque wrench. Tightening torque: Bolts (1) = 80 Nm 99
77364
Initial module DIRECT DISC 520 Comfort: Nuts (2) = 450 Nm. Safety module DIRECT DISC 610: Nuts (2) = 380 Nm. (Fig. 99)
Feed drum cap DIRECT DISC 610
ATTENTION! 3
Imbalance through missing or damaged caps. Machine damage. – Replace missing or damaged caps (3) immediately.
4
– The outer feed drums (4) must always have the cap (3) fitted.
5 77365
100
Ensure that the drainage opening (5) at the bottom of the conveyor cones is always open. This is the only place for draining water that has collected here (e.g. high-pressure steam cleaning). (Fig. 100)
