Text Reference Pilot System
4
3
1
8 6 2
5 7
10
9
69
Pilot Controls and Valves Pilot controls in the cab include: - left (1) and right (2) travel pedals - left (3) and right (4) travel levers - hydraulic hammer pedal (5) (optional) - straight travel pedal (6) (optional) - left joystick (7) to control the swing and stick (SAE HEX pattern) - right joystick (8) to control the bucket and boom (SAE HEX pattern) - foot rest (9 and 10)
