Text Reference Pilot System
66
67
Hydraulic Activation Lever The hydraulic lockout lever (arrow) is shown in the LOCKED position in the top illustration. The engine will not start unless the hydraulic activation lever is in the LOCKED position. Raise the lever activation lever to the UNLOCKED position (bottom illustration) to energize the implement hydraulic lockout solenoid valve and allow the operator to move the implements. If the machine is running, the operator can lockout the implement controls by returning the lever to the LOCKED position.
