Text Reference Boom, Stick, and Bucket Circuits
Boom Cylinder
Snubber
Snubber
Stick Cylinder
Bucket Cylinder
139
Cylinders The boom, stick, and bucket use dual acting cylinders. The boom has a snubber for the rod end, while the stick uses snubbers on the rod and head end. Snubbers slow the speed of the cylinder as the cylinder reaches the end of the cylinder stroke.
