____________________________________________ Hydraulic system Hydraulic system The following pages contain a brief description of the hydraulic components and assemblies that are on the feeder breaker. The primary hydraulic system for this machine has been designed to provide hydraulic power for the conveyor drive motor, tram motors, tilt cylinders and lift cylinders. The secondary hydraulic system for this machine has been designed to provide hydraulic power for the belt spreader cylinders, roof cylinders, the foot cylinders, and the tailpiece cylinders
© BUCYRUS AMERICA, INC.
WARNING! This section is intended only to familiarize the user with the hydraulic components of the feeder breaker. All hydraulic maintenance should be performed only by a qualified technician with the knowledge of the function of the components involved. WARNING! Never disconnect a hydraulic hose if the circuit is pressurized or if there is a load on the circuit. If a hose is disconnected while the circuit is pressurized or a load is on the circuit, the load will fall causing damage to the machine or serious injury or death to you or other workers. Fig. 29: Hydraulic component locator feeder breaker
1. 2. 3. 4. 5. 6. 7. 8.
Oil tank Hydrostatic pump Gear pump Primary valve bank Secondary valve bank Tilt and lift cylinders Tram motor Conveyor motor
9. 10. 11. 12. 13. 14. 15. 16.
Belt lift/spreader cylinders Tail pulley cylinder Roof anchor cylinder Counter-balance cartridge Flow divider, power fill Ball valve Dual relief manifold Filter service pressure gauge
17. 18. 19. 20. 21.
Charge pressure gauge Selector valve proportional detented valve Air/oil heat exchanger Filter (pressure (2), charge, aux pressure, return) 22. Tank fill filter 23. Filter, in-line, non-bypass 24. Return manifold
25. Flow control, heat exchanger 26. Tank fill hand pump 27. Check valve 28. Logic check valve 29. Loop flushing valve 30. Foot cylinders (not shown)
