________________________________________________ Maintenance tram reducer
Change oil in the tram reducer (Fig. 68). Clean all dirt and debris from and around the level and fill plugs. Rotate reducer until drain plug is at the 6 o’ clock position and remove drain plug and allow the oil to completely drain. Clean and reinstall drain plug. Rotate reducer until plugs are at the 12 o’ clock and 3 o’ clock positions. Add oil (80W-90) through the fill hole until fluid begins to flow from the check plug. When filling the reducer, allow enough time for all cavities inside the reducer to fill. Install level and fill plugs. Do not overfill reducer. Fig. 68: Tram reducer oil change
Fill plug location when at 12 o’ clock
Check plug location when at 3 or 9 o’ clock
To drain, position a plug at 6 o’ clock
