________________________________________________ Maintenance foot cylinder
Grease the foot cylinder (2) through the fittings located on the rod and cylinder eye (4 places) (Fig. 60) with Spec. 100-3. Pump new grease into the fitting until old grease can be observed coming out of the bushing. Fig. 60: Foot cylinder grease points
Foot cylinder (2) (grease fitting located on rod and base end)
Every 3 months breaker electric motor
Lubricate the breaker power unit electric motor with Spec. 100-3 through the two (2) grease fittings located on the lubrication manifold (Fig. 61) located on the right side of the machine. Pump only one or two pumps of grease into each fitting. NOTICE! Incorrect grease or over greasing may cause serious damage to the electric motor. Fig. 61: Breaker electric motor
Electric motor central lubrication panel
