Operation____________________________________________________ TORQUE HUB – CT45 SERIES; 1:110.07 purpose The torque hub provides the crawler tracks with high torque by reducing
1---TRAM MOTOR 2---FILL LEVEL SITE PLUG 3---OIL LEVEL PLUG 4---MOTOR ADAPTOR PLATE PULLER HOLES
construction The torque hub is a wheel hub drive type that is assembled with high-
strength steel machined and cast parts. The gear reduction is achieved through a three-stage planetary gear sets. A center sun-gear can be disengaged for free wheeling (see the “Towing and Free Wheeling” section).
_________________________________________________________________ VUVA / 05 ________ DBT AUSTRALIA – BELT TAILPIECE © 5.38
© DBT AUSTRALIA 2007
the speed of the hydraulic motor through gear reduction at a ratio of 1:110.07. For final speeds, torque ratings and drawbar pull see the “Drive Stats” heading under the “Belt Tailpiece System Statistics” section.
