___________________________________________________Operation LUBRICATION SCHEDULE – CRAWLER MOUNTED TAILPIECE yearly Change oil in all gearboxes and planetary torque hubs. For locations and detailed information refer to the maintenance heading under the proper section for the desired component in question (follow the greasing instructions in the “Lubrication System” section).
monthly If fittings are provided in the head of the pin, apply grease to all of the connection joints found on the dolly wheels, stab shoes, belt lifter, sideslew, and any other cylinder connection points. For locations and detailed information refer to the maintenance heading under the proper section for the desired location in question (follow the greasing instructions in the “Lubrication System” section).
weekly Grease all bearings found on the idler rollers, tail pulley, and crawler
© DBT AUSTRALIA 2007
chain take-up sprocket. For locations and detailed information refer to the maintenance heading under the proper section for the desired location in question (follow the greasing instructions in the “Lubrication System” section).
after 1st 50-hours Change oil in all planetary torque hubs. For locations and detailed information refer to the maintenance heading under the proper section for the desired component in question (follow the greasing instructions in the “Lubrication System” section).
