Operation____________________________________________________ LUBRICATION SYSTEM – CUSTOMER SUPPLIED Follow the procedure supplied by the manufacturer of the lubrication system inplace on this BTP. Use the information below as a general guideline only! If no central location has been specified or fabricated, then each bearing or roller must be individually greased. The bearings without any grease fittings are sealed and do not need any form of lubrication the entire life of the bearing.
purpose The lubrication system provides a means of greasing the tail pulley and idler roller bearings found on the BTP.
construction Not applicable. Varies from vendor to vendor. maintenance Visually examine all fittings for leaks and replace as required. Grease
operation Clear away dust, dirt and old grease from grease fittings and apply
grease with a grease pump. Provide several pumps of grease to bearing or until fresh grease emerges from bearings. When finished, cover grease fitting with a smear of grease to avoid rust build up.
Broken or damaged fittings can prevent grease from reaching the bearings and severe damage may occur. IMPORTANT
_________________________________________________________________ VUVA / 05 ________ DBT AUSTRALIA – BELT TAILPIECE © 5.12
© DBT AUSTRALIA 2007
weekly, all grease fittings on the manifold or bearing fittings using several pumps of Multipurpose EP 1 Lithium base grease.
