2550
66 ENGINE: 17. FUEL FILTERS - Replace filters Open the left side panel of the engine compartment.
1
WARNING Never use gasoline, solvent or other flammable fluid to clean parts. Use exclusively qualified, nonflammable, non-toxic commercial solvents. When using compressed air for cleaning parts, use safety glasses with side shields or goggles, so as to reduce the danger for personal injuries cause by flying particles. Limit pressure to 2 bar, in accordance with local and national regulations. Clean the base of the support and the surrounding area. Loosen the filters indicated in the figure. Clean with a dry rag the support area contacting the filter gaskets.
Every 1000 hours 18-19. TORQUE CONVERTER/TRANSMISSION Changing the oil and cleaning the suction filters
WARNING AVOID POLLUTING THE ENVIRONMENT. Dispose of batteries, lubricating, cooling and hydraulic fluids, filter elements or cleaning rags impregnated with these fluids in accordance with national and local regulations, classifying these materials as polluting, hazardous or dangerous. With the transmission oil hot, remove the cover as indicated and remove the plug underneath, draining the oil. To facilitate the draining, remove plug C.
D255-2M051
Replace gaskets "1" fill the new filters with fresh fuel and smear a film of engine oil on the gasket, and tighten them against the support. Then, turn 1/2 turn further. Study SAFETY RULES in the front of this manual thoroughly for the protection of machine and safety of personnel
