Removing the USB/LED/Power/Card Reader Board 1. Remove the upper cover. See “Removing the Upper and Lower Covers” on page 38. 2. Remove the three (3) securing screws as shown.
SSD SKU
HDD SKU
Step
Size
Quantity
HDD SKU: USB/LED/Power board
M2*3 (NL)
3
SDD SKU: USB/LED/Power board
M2*3 (NL)
4
Screw Type
3. Lift the board to expose the USB/LED/Power board to mainboard cable.
Chapter 3
51
