Main Unit Disassembly Process Main Unit Disassembly Flowchart
Screw List Step
Screw
Quantity
Color
Part No.
WLAN
M2*3 (NL)
1
Black
86.S0207.001
USB/LED/Power Board (HDD SKU)
M2*3 (NL)
3
Black
86.S0207.001
USB/LED/Power Board (SSD SKU)
M2*3 (NL)
4
Black
86.S0207.001
SSD Module
M2*3
2
Black
86.S0207.001
Mainboard
M2*3
1
Black
86.S0207.001
Speaker Module
M2*3
4
Black
86.S0207.001
HDD Module
M2.5*4
2
Black
86.D01V7.001
HDD Carrier
M3*3.5
4
Black
86.TDY07.003
Thermal Module
M2*3
3
Black
86.S0207.001
