Removing the LCD Panel 1. Remove the LCD Bezel. See “Removing the LCD Bezel” on page 43. 2. Disconnect the MIC cable. See “Removing the MIC Board” on page 45. 3. Remove the five (5) securing screws from the LCD Module.
Step LCD Panel
Size M2*4 (NL)
Quantity
Screw Type
5
4. Grasp the left hinge and pivot down before pulling up. 5. Remove it from its housing well.
