Boot This menu allows the user to decide the order of boot devices to load the operating system. Bootable devices includes USB drives, the onboard hard disk drive and the DVD drive in the module bay.
Information
Main
Phoenix SecureCore(tm) Setup Utility Security Boot Exit Item Specific Help
Boot priority order: 1. IDE0 : WDC WD3200BEVT-22ZCT0-(S1) 2. IDE CD : Optiarc DVD RW AD-7580S 3. PCI LAN: Atheros Boot Agent 4. USB HDD : 5. USB CDROM : 6. USB FDC : 7. USB KEY : 8: Excluded from boot order:
F1 Help ESC Exit
Chapter 3
Select Item Select Menu
F5/F6 Enter
C h a n g e Va l u e s Select SubMenu
Keys used to view or configure devices: Up and Down arrows select a device. <+> and <-> moves the device up or down. <f> and <r> specifies the device fixed or removable. <x> exclude or include the device to boot. <Shift+1>enables or disables a device. <1 - 4> Loads default boot sequence. F9 F10
Setup Default Save and Exit
33
