Replacing the Camera Module

8. Replace the four screws to secure the panel within the LCD module.

IMPORTANT:When replacing the screws in the LCD brackets (red callout) do not use the screw holes marked with ‘X’. These slots are reserved for the Bezel securing screws.

1. Place the Camera Module into the assembly so the pins are aligned. Press down to secure the Camera

Module in place with adhesive. 2. Reconnect the camera to the camera cable.
