The following thermal compounds are approved for use: •
Eapus XR-PE
1. Remove all traces of thermal grease or pad adhesive from the Thermal Module using a lint-free cloth or cotton swab and Isopropyl Alcohol, Acetone, or other approved cleaning agent. 2. Apply a small amount of thermal grease or the supplied thermal pad to the centre of the heat sink. There is no need to spread grease manually, the force used during the installation of the Thermal Module is sufficient. 3. Place the CPU into the socket. Take note of the Pin 1 locator in the image below.
4. Turn the CPU socket latch 180 degrees clockwise to the Lock position.
Replacing the Thermal Module IMPORTANT:Ensure all thermal pads are in place before replacing the Thermal Module. The following thermal pads are approved for use: • • •
Silmore GP50 Honeywell Jet Motor 7762
The following thermal compounds are approved for use: •
Eapus XR-PE
1. Remove all traces of thermal grease or pad adhesive from the Graphics Card and CPU using a lint-free cloth or cotton swab and Isopropyl Alcohol, Acetone, or other approved cleaning agent.
Chapter 3
101
