3. Lift the LCD Panel out of the casing as shown.
Removing the LCD Brackets and FPC Cable 1. See “Removing the LCD Panel” on page 91. 2. Remove the four securing screws (two on each side) from the LCD Panel brackets.
2
Step LCD Brackets
Size
Quantity
M2*3
Screw Type
4
3. Turn the LCD Panel over on a clean surface. 4. Remove the cable from the panel as shown (2).
2
92
1
Chapter 3
