Figure 4–4.
4–5. CHECKING PLUGS AND OPENINGS Carefully check all sides and the bottom of the transmission for loose or missing plugs. a. Pressure Plugs. Check that .4375–20 UNF2A pressure plugs are tightened to 10–13 N∙m (7–10 lb ft). b. Fluid Drain Plug. Check that the drain plug is tightened to 30–40 N∙m (22–30 lb ft) . c. Tachograph Plug. If present, tighten to 60–67 N∙m (44–49 lb ft).
44
