The right corner screen information gives you the available function keys and the specified test number. • • • • • •
Space ESC F1 F2 Enter Test Times
Enables/disables the item Exits the program Help Tests the selected item(s) Opens the available suboptions Indicates the number of tests to perform.
Note: The F1 and F2 keys function only after you finish configuring the Test option.
PQA Diagnostic Program Error Code and Messages \ Error Code
Message
Spare Part/Action in Sequence
16XX
Backup battery error
Backup battery
1XXX
CPU or Main board error
1. Reload BIOS default setting. 2. CPU 3. Main board
2XXX
Memory error
1. Reconnector CPU(IMM module) 2. DIMM 3. Main board
3XXX
Keyboard error
1. Reconnector Keyboard 2. Keyboard 3. Main board
4XXX
Video error
1. Main board
5XXX
Parallel Port error
1. Main board
6XXX
Serial port or Main board error
1. Main board
7XXX
Diskette drive error
1. Diskette drive 2. Main board
8XXX
Hard disk error
1. Reload BIOS default setting. 2. Hard disk 3. Main board
9XXX
CD-ROM error
1. Reconnector CD-ROM cable 2. CD-ROM drive 3. Main board
10XXX
CPU or Main board error
1. CPU 2. Main board
11XXX
Pointing device error
1. Reconnector Keyboard 2. Keyboard 3. Main board
System
