Parameter ECP DMA
Description Assigns DMA channel 1 or DMA channel 3 for ECP parallel port function. This item becomes active only if you select Extended Capabilities Port (ECP) as the operation mode. Options: DMA 1 or DMA 3
Speaker
Enables or disables the internal speakers. You can override this by toggling Fn-F6 during computer operation. Options: Enabled or Disabled
Boot Display Device
Sets the display on boot-up. When set to Auto, the computer automatically determines the display device. If an external display device (e.g., monitor) is connected, it becomes the boot display; otherwise, the computer LCD is the boot display. When set to Both, the computer outputs to both the computer LCD and an external display device if one is connected. Options: Auto or Both
Security The Security screen contains parameters that help safeguard and protect your computer from unauthorized use. .
Chapter 2
25
