Pneumatic Tires Adding Liquid Weight It is acceptable to add liquid ballast to the tire / wheel assembly on your Mahindra Tractors. Consult your Local Tire Dealer or Manufacturer of Tires for ballasting process. Inflation Keep tires properly inflated to the pressure as shown in the Chart below. Under inflation will damage tire cord and may cause the tire to slip on the rim and tear out the tube valve stem. Over inflation results in excessive slippage, causing rapid tire wear. Air pressure should be checked once a week with an accurate low pressure gauge having one pound graduations. Air pressure should not be allowed to drop or exceed the recommendations. Always see that the tire valve caps are in place and screwed tight. The caps prevent loss of air through the valve core. Further, they prevent debris from entering and damaging the valve core and air chamber in the tires. Exceptions (Rear Tires only) When plowing with a moulded plow, the left hand or land wheel should be inflated to 2 p.s.i. lesser than right hand or furrow wheel. Chart A-1 Tire Load Rating Model
Side
Tire Size
Tire Type
Tire Capacity @ 25 mph kg @ kg/cm2
Rolling Circumference (mm)
Front
28 x 8.5 - 15, 6PR, TTL
Industrial
1309 @ 3.17
2108
Rear
43 x 16 - 20, 4PR, TTL
Industrial
1959 @ 0.59
3251
Front
12 x 16.5, 6PR, TTL
Industrial
1918 @ 2.82
2489
Rear
16.9 x 24, 8PR, R4, TIT
Industrial
2909 @ 1.26
3810
Front
9.5 x 16, 6PR, R1 HTL
Ag
632 @ 1.41
2540
Rear
14.9 x 24, 6PR, R1 HTL
Ag
1364 @ 0.79
3810
Front
14 x 17.5, 6PR, TTL
Industrial
2191 @ 2.11
2718
Rear
19.5 x 24, 8PR, R4, TIT
Industrial
3000 @ 1.10
3912
Front
9.5 x 20, 6PR, R1 HTL
Ag
750 @ 2.11
2870.20
Rear
16.9 x 24, 6PR, R1 HTL
Ag
1855 @ 0.94
3987.8
3535
4035 / 4535
4035
5035
56
