Switches 3. Alignment of Manual-mark with pointer - Operates Manual mode This switch can be used when the “PTO Engage - Disengage Switch” is in ON position. Keeping this switch in MANUAL-POSITION, will FORCE the PTO shaft rotation in RAISED as well as LOWERED position of implement. The “PTO Engage - Disengage Switch” will be CONTINUOUSLY-GLOWING when this switch is in MANUAL mode.
While the PTO is in MANUAL-MODE, some inadvertent movement of personnel near the PTO shaft can prove fatal.
POWER TAKE OFF PTO is operated electrically. PTO can be operated by using a combination of “PTO Engage - Disengage Switch” and “PTO Mode Switch”. After switching ON the “PTO Engage - Disengage Switch” the operator has a CHOICE to select AUTO or MANUAL MODE through “PTO Mode Switch”. The PTO will turn-Off if the “PTO Engage - Disengage Switch” or “PTO Mode Switch” is in OFF position. Refer table shown for combinations of PTO Operations. PTO ON / OFF Switch
PTO Control Switch
PC Lever
PTO Switch
PTO Shaft
ON
Manual Mode
Either raised or lowered
Glows
Rotates
ON
Auto Mode
Raised
Blinks
Stationary
ON
Auto Mode
Lowered
Glows
Rotates
38
