Instrument Cluster Turn Indicators (LH/RH) LH and RH turn indicator is provided to indicate the direction of turning. A blinking turn indicator implies that either LH Turn Signal or RH Turn Signal indicator of tractor is ON. High Beam Indicator It glows when Head Lamps are operated in High Beam. Heater Indicator When the key is turned to 2nd position, the Heater Indicator glows to indicate the activation of heater element provided in engine's intake manifold. The indicator continues to glow for approx. 42 seconds. A timer controls this time. 1. Turn the key to "ON" position and hold it till the heater indicator is put-off. 2. Crank the engine when the heater indicator light is put off after approx. 42 seconds. Parking Brake Indicator It glows when parking brake or foot brake pedals (latched together) is applied. 4WD Indicator It glows when 4WD is engaged. Battery Charging Indicator This indicator will glow if battery is not getting charged. Once the engine is running, this indicator should go OFF, if the Battery is getting charged. If the indicator glows continuously even when the engine is running above low idle rpm of the engine, the cause should be investigated to prevent complete discharge of battery and possible damage of alternator. Voltmeter This gauge indicates the battery voltage at all times.
Engine Low Oil Pressure Gauge This gauge will be in RED Zone if Engine lubricating oil pressure is less while engine is operating. The pointer will be in GREEN Zone when pressure is Okay. After putting ignition switch in "ON" position, the oil pressure gauge pointer should be in RED Zone. When the Engine is running and healthy it should be in GREEN Zone. If the pointer is in RED Zone, the problem should be eliminated before starting the engine.
