Brake Pedal Free Play Check and adjust brake pedal free play Measure free play of pedal stroke (A). Ensure free play is within specified limits. If free play is not within specified limits, adjust brake linkage as shown below.
Free Play - Distance 1.57 to 1.77 inch (40 to 45 mm)
1. Loosen jam nut (B). 2. Turn the Turn Buckle (C) anti-clockwise to increase play and clockwise to decrease play.
A
B C
Brake Setting from RH Side
B C
Brake Setting from LH Side
98
35 Series PST-Cabin, Models - 3540P & 3550P
