Three Point Linkage Adjustable Lift Rod RH Use turn handle (A) on the adjustable lift rod to raise or lower the Telescopic Lower Link for side-to-side leveling of implement with respect to ground.
B
1. Release the levelling gear box operating lever (A) out locking clip (B).
A
2. Rotate turn handle (A) clockwise to raise the lower link or anti-clockwise for lowering. 3. After adjustment, make sure turn handle is secured with the locking clip. Always transport the implement with turn handle in this position.
Locked
Unlocked
Lateral Stabilizers These are provided for adjustment of width between two lower links according to varying implement spans. These enable to keep the implement in either FIXED or FLOATING position. Placing the locating pin in (C) position shall keep the stabilizer and implement in “Fixed” position.
D C
Placing the locating pin in (D) position shall keep the stabilizer and implement in “Float” position. We recommend to use the fixed position while transporting the implement.
Fixed Lift Rod LH There are two holes provided on the lift rod LH. This is provided to adjust the height of lower link LH as desired. To adjust the height of the lower link, remove locking pin out of the lift rod-Lower link and adjust the height by putting the locking pin in the required hole as needed.
62
35 Series PST-Cabin, Models - 3540P & 3550P
