Controls Tilt Steering The steering can be tilted towards or away from the operator as per the need and convenience of operator and is recommended to be done in tractor parked condition. Tilt Adjustment 1. Park the tractor safely. 2. Press the tilt steering pedal by foot. 3. Tilt the steering wheel to desired position. 4. Release foot pressure on the pedal. 5. To position the steering wheel back, press the tilt steering pedal to allow the steering wheel to travel back to the top position. It will go back automatically.
Attempting to adjust the steering wheel while driving the tractor may cause the operator to lose control of the tractor.
4WD Engagement Lever
Lock the steering wheel in position before driving the tractor.
This lever is located on LH side of operator’s seat. It is used to engage or disengage the drive to front wheels and is recommended to be done in tractor stand still condition. 1. Depress clutch pedal and stop the tractor motion completely. 2. Press the lever down to engage the drive. 3. Lift the lever upwards to disengage the drive. Engaged
Disengaged
Do not engage or disengage the 4WD Engagement lever while the tractor is in motion. 44
35 Series PST-Cabin, Models - 3540P & 3550P
