Instrument Cluster B. Trip Hour Meter : By using KEY PAD switch LCD Display can be changed to show trip hours value along with TRIP warning indicator. Trip hour meter operator can be ‘RESET’ by pressing (ENTER key) of Key Pad Switch for more than 1.2 Secs during ignition "ON" position. Process to Reset Trip Hour Meter •
Turn "ON" the ignition switch and wait till complete self checking.
•
Select trip hour display of instrument cluster by pressing enter button of Key Pad Switch.
•
Hold enter button more than 1.2 Secs when display shows Trip hour. Now Trip Hour display will show 00 hours.
C. Time Left for Next Service/Service Reminder Indicator : 1. Time Left for Next Service Operator can see service due hours on display by using Key Pad Switch to display time left for next service along with Service Reminder indicator. Process to display Time Left for Next Service •
Turn "ON" the ignition switch & Wait till complete self checking.
•
Select Time Left For Next Service display of instrument cluster by pressing enter button of Key Pad Switch. Now Time Left For Next Service display will shows next service hours.
UP Key DOWN Key
2. Service Reminder Indicator This indicator will glow continuously when the service of tractor is due.
ENTER Key
This function is set for first 50th hours & thereafter for every 250 hours of engine running. The operator is thus indicated for General Service Due. Resetting can be done by Authorized Mahindra Dealer after general service. D. Clock Indicator : Operator can see Real Time on display in HH-MM format along with Clock warning Indicator by using Key Pad Switch. Real time mode is 24 Hours. Real Time value must be reset (00-00) after battery ON/OFF. Operator can set CLOCK TIME by using KEY PAD SWITCH. Process to set Real Time Clock : 1. Turn “ON” the ignition switch & Wait till complete self checking 2. Select Real Time Clock display of instrument cluster by pressing enter button of Key Pad Switch. 34
35 Series PST-Cabin, Models - 3540P & 3550P
