Instrument Cluster
4
3
2
1
5
22
6
21
7
20
8
19
9
18
10
17
11
16
12 13 14 15
Instrument Cluster The Instrument Cluster is a descriptive unit that gives the user various indications about the working of the tractor and its various features. It consists of the following. 1. Right Turn Indicator 2. Engine RPM Meter 3. LCD Display 4. Left Turn Indicator 5. Forward/Reverse & PTO Neutral Indicator 6. Coolant Temperature Gauge 7. Heater Indicator 8. Parking Brake Indicator 9. Battery Charging Indicator 10. High Temperature Warning Indicator 11. Low Oil Pressure Indicator 32
12. Hour Counter 13. Trip Hour Meter 14. Time Left for Next Service / Service Reminder Indicator 15. Clock Indicator 16. Check Engine Indicator 17. Malfunction or MIL Indicator 18. 4WD Indicator 19. Air Filter Clog Indicator 20. Water In Fuel Indicator 21. Fuel Level Gauge 22. High Beam Indicator 35 Series PST-Cabin, Models - 3540P & 3550P
