Lubrication Oil Transmission, Hydraulics and Oil Immersed Brakes Use mild EP type gear lubricant. They should meet API GL4 performance category with suitable additives compatible for paper based brake liner and taking care of noise. Use viscosity based on the expected air temperature range during the period between oil changes. Please refer Oil Specifications Chart for oil specifications at different range of ambient temperatures. Following oils are recommended. 1. GULF Universal Tractor Transmission Fluid 2. Exxon Torque fluid 56 3. Shell Donax TD 4. Mobil fluid 424 5. Tractelf BF 12 6. Tractelf C4 - 1000 7. Hydro Clear Power Train Fluid Other brands may be used if they meet all the specifications and performance levels of the above. Chassis Lubricant (CL) Use good grade of grease designed for pin and bushings on agricultural equipment. Lithium or aluminum complex type grease with high viscosity base oil, tackiness and molybdenum disulphide are suitable. Grease approved for the NLGI certification mark GC-LB are recommended. Grease must be SAE Multipurpose High Temperature Grease with Extreme Pressure (EP) performance and capable of operating at assembly temperatures above 150°C (302°F) Depending upon the expected ambient temperature range during the service interval, use grease as shown on the Oil Specifications Chart. Front Axle Use gear oil complying to API GL5, MIL-L-2105D specifications. Please refer Oil Specifications Chart for oil viscosity grade at different range of ambient temperatures. Following oils are recommended, 1. Chevron RPM Universal Gear Lubricant SAE 80W90 2. Texaco Havoline Gear Oil 80W90 3. Total Transmission DA 80W90 4. Shell Spirax Heavy Duty 80W90 5. Mobilube HD Plus 80W90
NOTE : Universal Tractor Transmission Oil. Oil shall meet API GL4 performance category. Factory filled oil is Tractelf MM H3 and is subject to change in future. Grease Type
Temperature Limits
Arctic Grease
Below -30°C (-22°F )
SAE (NLGI) #0
-30°C to 10°C (-22°F to 50°F)
SAE (NLGI) #1
-20°C to 20°C (-4°F to 68°F)
SAE (NLGI) #2
14°F to 122°F (-10°C to 50°C)
* Factory filled oil is SAE80W90EP complying to API GL5, MIL-L-2105D specifications and is subject to change in future.
Oil Specifications Chart (Table A) Sr.
Application
No.
102
Capacity
Anticipated minimum air temperature
Gallon / Quarts
–40 to +880F
–22 to +880F
–4 to +1220F
SAE 15W40
SAE 15W40
SAE 15W40
1
Crankcase
2.00 / 8.00
2
Transmission & Hydraulics
10.03 / 40.12
3
Lubrication Fittings
4
Front Axle
SAE 75W UTTO
C. L. 2.24 / 8.96
+32 to +1040F +50 to +1220F SAE 15W40
SAE 15W40
SAE 80W UTTO listed above. NLGI No. as recommended
SAE75W90EP
SAE80W140EP
SAE80W90EP
SAE80W140EP
SAE80W90EP listed above for ambient temperature range - 40F to 1040F 35 Series PST-Cabin, Models - 3540P & 3550P
