Control, operation
Operating manual
Working with the machine
Before carrying out any work, the machine must first be placed on level and firm ground. If necessary, prepare the working area and remove obstacles. If possible, all work with the machine should be carried out through the idler A.
3.4.4
Operating the working attachment
Fig. 3-65
Operating the working attachment
Caution! The machine is equipped with PCSA controls as standard. On request, the machine can be fitted with a different control system (e.g. LIEBHERR control). For such machines, observe the instructions in the respective separate operating manual. The left joystick (1) controls the stick and swivelling movements: a and b: Stick is extended or retracted. c and d: Uppercarriage is swivelled to the left or right. The right joystick (2) controls the boom and grapple movements: e and f: Grapple is closed or opened. g and h: Boom is lifted or lowered. Moving the stick: The stick is moved by operating the left joystick 1. Push the joystick back a: Stick moves in direction a Push the joystick forward b. Stick moves in direction b.
