Control, operation
Operating manual
Operating and control elements
Fig. 3-18
Electrical inputs
Pages 4 to 5 provide an overview of the status of the various electrical inputs. The values are provided primarily for a quick system diagnosis, e.g. by LIEBHERR customer service technicians. "
" indicates that the input is not activated.
"
" indicates that the input is activated.
"NC" below the input designation indicates that the respective input is deactivated via the software. M4/time indicates the set delay time for the windscreen wiper interval mode. B19/ time indicates the set delay time for the low idle automatic function. To exit the menu: Press the BACK button. The display returns to the operator's menu.
Menu: errors (operating errors and electrical system errors)
Fig. 3-19
Errors menu
This menu offers 3 choices for selection: list Exxx to obtain a list of the machine errors detected by sensor devices. E-elec. to obtain a list of the electrical wire faults of the LCD display stored during operation. list S-Exxx to obtain a list of the machine errors displayed when the service plug is connected. To select the error type: Press the UP and/or DOWN buttons. The preceding or next error type is highlighted in black.
copyright by
3 - 18
R 984 C Litronic High Rise / 11140259
