Control, operation
Operating manual
Operating and control elements
Fig. 3-14
Machine movement hours menu
Page 2 indicates the operating hours of: lled by means of joysticks Page 3 indicates the operating hours of: ar (no activation from model A 934)
Fig. 3-15
Technical data
Page 4 provides information regarding machine data: typ, serie: Excavator model with type and serial number ver: Software version (machine and diesel engine) volt: Current operating voltage (V) The "nom" and "hours" fields are not used in this machine. To exit the menu: Press the BACK button. The display returns to the operator's menu.
copyright by
3 - 16
R 984 C Litronic High Rise / 11140259
