Control, operation
Operating manual
Operating and control elements
Fig. 3-8
Operator's menu
Scrolling through the operator's menu: Press the arrow buttons UP and/or DOWN. The previous or next menu is displayed on a black background. Depending on the equipment of the machine, there might be more menus in addition to the above listed. These can be accessed by scrolling to the bottom of the screen. Select a menu: The menu showing a black background is selected. Press the Menu button. The submenu of the selected function is displayed. Press the BACK button. The submenu is closed. Symbol
Description Reset daily operating hours counter
Confirmation of service interval
ings for working tool (optional equipment) Operating hours, machine data
Status of hydraulic pumps and electrical inputs/outputs
Detected and saved errors
Time
copyright by
3 - 12
R 984 C Litronic High Rise / 11140259
