Control, operation
Operating manual
Operating and control elements
S10 - Headlights of revolving deck, roof and attachment The switch is assigned several functions that are operated with repeat actuation: dlights are automatically switched off after 3 minutes. light is switched off immediately. The revolving deck and roof headlights are switched off after 3 minutes. S11 - Windscreen washer system Windscreen washing solution is sprayed onto the window while the windscreen wiper is on. S14 - Windscreen wiper The switch is assigned several functions that are operated with repeat actuation:
S17 - Slewing gear brake Applies/releases the mechanical slewing gear brake. May only be used when the uppercarriage is not in motion. S18 - Overload warning system (optional equipment) The overload warning system warns the machine operator with a visual signal (screen icon) and an acoustic signal (buzzer sound) when the permissible maximum load is reached. The warning signal should ensure that the permissible load is not inadvertently exceeded. In the event of a warning signal, reduce the extension of the attachment or lower the load to the ground without increasing the extension. S19 - Release auxiliary function (grapple rotator) The control console allows operators to activate the rotators of the working tools (e.g. grapple), the quick-change adapters and similar functions. S20 - Low idle automatic The idle automatic function automatically reduces the engine speed without actuation of the joystick or the travel pedals, saving fuel and reducing noise. By touching the joystick or the pedals, the engine speed returns to the initial level. S21 - no function assigned
S22 - Auxiliary headlight (optional equipment) Activates the auxiliary headlight S36 - Cold start system Activates the cold start system. When the button is pressed, ether is spray into the suction section of the diesel engine. While the engine is running or at operating temperature, the cold start system cannot be actuated.
copyright by
3-4
R 984 C Litronic High Rise / 11140259
