Fuses and relays
Before exchanging a fuse or relay, set the battery main switch to position 0 (OFF).
4.4.1
Fuse box E50
Fig. 4-3
Fuse box E50
The fuse box E50 is located behind the door to the engine compartment. Remove the lid of the fuse box and close it after the fuse has been replaced. F19
15 A
Diesel engine
F20
80 A
Main fuse
F22
7.5 A
Reserve
F31
7.5 A
Heating and a/c system terminal 15
F32
15 A
Heating and a/c system terminal 30
F33
15 A
Reserve
F34
15 A
Reserve
F35
15 A
Reserve
F36
15 A
Reserve
F37
15 A
Reserve
F109
50 A
Flywheel
K16
Starter relay
K43
Engine stop relay
K66
Cylinder shut-down relay
K93
Cold start system relay
K103
Diesel engine ON (12 V for operating hours counter) relay
K141
Relay E5
K280
Relay E150
K288
Main relay terminal 15
K360
Headlight relay
