Control, operation
Operating manual
Installation and removal of attachment parts
A Industrial stick 1 Lock pin
3.5.3.4
B Suspension system of working tool 2 Half shell at suspension tackle
Releasing and locking
Fig. 3-79
Control elements, releasing (R)
Fig. 3-80
Control elements, locking (L)
S47 R
Push button / quick-coupling system Push button / release (lock pin is retracted)*
L
Push button / locking (lock pin is extended)*
For safety reasons, two control elements must be operated simultaneously to move the lock pin. With one hand, press the button S47 and then press the button L or R with the other hand (two-hand control). You can then release the button S47, and continue to operate the lock pin with the buttons L or R (holding function). *
Standard equipment; with other options of the "Rotate grapple" function (optional equipment), the operation can be carried out by means of the left or right joystick.
Releasing and locking: The auxiliary function must be activated (switch 19, LED on). Press and hold the button S47. The quick-coupling system is activated. Press and hold the right button R. The buzzer sounds. The lock pins are retracted. The "quick-change adapter" icon appears on the screen. The quick-change adapter is released.
