Malfunctions
Operating manual
Fuses and relays
F12_3 25A fuse / working light
F137 8A fuse / Reserve
F12_4 25A fuse / working light
F138 100A fuse / Service circuit supply
F12_5 25A fuse / working light
F139 100A fuse / Engine control system
F12_6 25A fuse / working light
F140 15A fuse radio box
F20_1 100A fuse / supply cabin Kl15
F141 15A fuse cigar lighter
F20_2 100A fuse / supply E1005 Kl15
F142 15A fuse service socket
F20_3 100A fuse / charging current
F143 25A fuse service lighting
F20_4 100A fuse / Kl30 floodlight
F144 15A fuse ladder control system
F20_5 100A fuse / Kl30 counterweight floodlight
F145 Reserve
F20_6 100A fuse / engine
F152 25A fuse / Quantum
F20_7 8A fuse / E1003
F164 7,5A fuse / E1003
F37
25A fuse / Ether
F166 Reserve
F119
8A fuse / Kl30
F167 25A fuse / Foot heating option
F120
50A fuse / air conditioning
F169 15A fuse / Charging
F121
50A fuse / air conditioning
F170 Reserve
F122
15A fuse / optional windshield wiper
Power connection box E1003 is located in the cab elevation.
4.3.2
Cabin connection box E1005 All other fuses and relays are on the cabin connection box E1005. The cabin connection box E1005 Danger Incorrect or bypassed fuses do not offer the machine's operator or the electrical system the required degree of protection. Only use original fuses. Never bypass electrical fuses.
LEC/en/Edition: 03 / 2021
If required, order replacement fuses from Liebherr.
4 - 12
copyright © Liebherr-Mining Equipment Colmar SAS 2021
MJFCIFSS
P 9250 E / 10360975
