Control and operation
Operating manual
Operating and control elements
The current operating hour will be confirmed as the last service interval carried out. Service work not carried out. Press the Back button. The submenu will be aborted.
Allocation of quantity limitation options to external input I1 menu (Kit input; for example, activation of the hammer pedal) Predefined quantity limitations have been assigned in this menu. The arrow opposite the symbol represents the current selection. In the example (see Fig. 3-15), quantity 2 is active if the specified attachment is serviced.
Fig. 3-15
Work equipment quantity limitation menu
Press the Up or Down arrow key. A different, predefined quantity (1-4) can be assigned (e g. when work equipment is changed). Press the Menu button. The selection is confirmed. The arrow displays the current selection. To exit the menu: Press the Back button. The submenu will be aborted.
Operating hours menu
LEC/en/Edition: 03 / 2021
Page 1 provides an overview of the operating hours of individual units, processes and operating types.
Fig. 3-16
3 - 22
Electric motor service life menu (example)
copyright © Liebherr-Mining Equipment Colmar SAS 2021
MJFCIFSS
P 9250 E / 10360975
