CONFIGURATION I=OR ~"r~ T"RO~.E I SK150THROUGHSK460I / / Jl CONTROLI
THIS TEST IS DESIGNED FOR STANDARD BOOM, ARM AND BUCKET. IF THE MACHINE BEING TESTED HAS ANY OPTIONAL EQUIPMENT, CHECK TO MAKE CERTAIN THERE WILL BE NO INTERFERENCE WITH THE CAB BEFORE PERFORMINGTHE TEST !! D, Arm Cylinder Cycle Time Test
FIGURE3.4
NOTE The measuringtime of the cylinder cycle does not include the cushion stroke times. Only measuretime up to the beginning of the cushion stroke. Movethe machineto a firm, level testing area. , 2. Place the machinethrottle control to "HIGH" idle and The KPSSWork Mode Switch to "H" Mode. See Figure 3.4.
BOOMUP BUCKET OUT CYLINDER EXTENDED CYLINDER RETRACTED FIGURE3.5 DONOTTIMECUSHION STROKE OF CYLINDER DURING TEST
NOTE The SKl15 and SK130 and machines do not have the KPSSWork ModeSwitch. Perform the test in the High Idle position only. 3. 4. 5. 6.
Fully extend BoomCylinder. SeeFigure 3.5. Fully retract Bucket Cylinder. SeeFigure 3.5. Fully extendthe Arm(retracting cylinder). At full stroke of the control, bring the armall the way in (extending cylinder) and measurethe time it takes for the arm cylinder to reach the cushion stroke. Recordthe time. See Figure 3.6. 7. At full stroke of the control, fully extendthe arm (retracting cylinder) andmeasurethe time takes until the cylinder reaches the cushion stroke. Recordthe time. See Figure 3.6. 8. Repeat steps 6 and 7 two more times. Average the recorded times and comparethe average to the Arm Cylinder Cycle Time Specification Chart. 9. Repeat steps 5 through 8 in the "FC" mode. Comparethe average readings to the Arm Cylinder Cycle Time Specification Chart.
FIGURE3.6 ARMCYLINDERCYCLETIME SPECIFICATIONS MODELCYLINDER POSITION SKl15 EXTENSION SKl15 RETRACTION SK130 EXTENSION SK130 RETRACTION SK150 EXTENSION S K160 RETRACTION ED180 EXTENSION ED180 RETRACTION SK200 EXTENSION SK210 RETRACTION
s~o
SK250 SK270 SK270 SK300 SK330 SK400 SK460
EXTENSION RETRACTION EXTENSION RETRACTION EXTENSION RETRACTION EXTENSION RETRACTION
H-MODE 3.7- 4.1 2.4- 3.0 3.7- 4.3 2.4- 3.0 3.6- 4.2 2.6- 3.2 3.6- 4.2 2.6- 3.2 3.7- 4.3 2.9- 3.5 3.8- 4.4 3.0- 3.6 3.8- 4.4 3.0- 3.6 4.5- 5.3 2.8- 3.4 4.2- 5.0 2.8- 3.3 Unit: Seconds
