SK115DZ ~ SK130LC IV OPERATIONAND CONTROLS 7. HYDRAULIC;)ILTEMPERATUREALARMLAMP
15.WORKLIGHT SWITCH(EUROPESPEC)
~ ~
ON- Lampilluminates when Hydraulic OiITemperature is 3°C(26.6°1=)or lower. OFF-Lampgoes out whenHydraulic Oil Temperature reaches10°C (40°F). Normaloperating temperatureof hydraulic oil is 45°C55°C(113OF- 131OF).
Depress this sideof switchto turn off all worklights.
16. ROTARY LIGHT SWITCH(EUROPESPEC)
8. DOZERCONTROL Toenergizesolenoidfor flow divider valve.
Depress this side of switchto turn on rotarylight. Depress this sideof switchto turn off rotary light.
17. HORNSWITCH
9. HEAT& AIR CONTROLS
C
Depress this side of switchto turn on all worklights.
Locatedon top of L.H. OperatorControl. Depressto soundhorn. Releaseto stop soundingof horn.
18. ENGINE EMERGENCY STOP CONTROL
~E
"~’~: Located at lower R.H. side of operator seat.= Pull control out to stop enginein caseoj emergency
A - FANSWlTCH Pushcontrol downto increase flow 1. OFFTurn switchcountemlockwise of warmwaterto heatercore. to left mostposition. 2. LOW Turn switch clockwise to D- INSIDE/OUTSIDEAIR first dot. CIRCULATION CONTROL 3. MEDIUM Turn switch clockwise to second Pull control up to circulate outside dot. air into cab. 4. FAST Turn switch clockwiseto third dol Pushcontrol downto stop circulation of outsideair into cab. B - PLUGS - Toallow installation of optional equipment. E- DEFROSTERSELECT CONTROL Pull controlup for air circulation C - HEAT TEMPERATURE CONfromunderseat. TROL Pushcontrol downfor air circulaPull control "UP" to reducethe tion behindseat. flow of warmwaterto heatercore.
19. FUELLEVELMETER F- Full tank, approximately 250liters (66 Gal.) e~
E- Emptytank, approximately 3 liters (8 Gal.) of fuel in Tank.
20. ENGINE COOLANTTEMPERATURE METER RED-Indicates enginecoolant temperatureis abovesafe operating temperature.ReduceengineRPMor stop engineand allow to cool. WHITE-Engine safe operating temperaturerange. BLUE-Enginecold range.
~~e
21. ENGINEHOURMETER 10 I01 01 01 01 01 Indicates actual hours enginehas ran.
10. 24V CIGARETTELIGHTER
B
ON- Pushin. OFF-Lighter "POPS"out. Thelighter shouldpop out within 30 seconds. If it doesn’t,haveit repaired. Donot uselighter for a 12Vpowersource.
22. FUELLEVELLAMP
I~
11.12V POWERSOURCE
Illuminateswhen fuel tanklevel is 14liters (3,7 Gal.)or less. Refuel immediatelyif Fuel Level Lampis illuminated.
23. ENGINEOIL PRESSURE LAMP ilp~
To allow use of accessoriesrequiring a 12VDC powersource.
Illuminates whenOil Pressureis belowsafe operatingpressure. Stop EngineImmediately and checkoil level if lamp comes on during operationof the machine.
24. BATTERYCHARGELAMP
!
12. AUTODECELERATION SWITCH(Europe ONLY)
~"~ Illuminates whenelectrical chargingsystemis not functioning properly. Checkthe charging systemif light comeson during operation.
Depressthis side to turn Auto Decel"ON", This will drop engineRPM to 1050,
25. ~
13. TRAVELALARMCANCELSWITCH Depressagain to turn Travel Alarm"OFF" AlwaysuseTrevel Alarm during allTrevel Operations
14. ENGINESTARTAID ICON Thisiconwill displayafter keyswitchis turnedto "HEAT" position.This systemservesto warmthe engineair intake when starting in coldclimates.
s~o~.,~s~
ENGINE COOLANTTEMPERATURE LAMP Illuminates whenengineco°lent temperaturerises ab°ve105°C(211°F)" If lamp comeson reduce engine RPMimmediately and stop operation to allow engineto cool downto safe operating temperature.
-- Depressthis side to turn Auto Decel "OFF".
26. HIGH TRAVELSPEEDLAMP 1~ Illuminates when the Travel Speed Select switch is "ON".
27. DIRTY ENGINEAIR CLEANER LAMP P,~dl
Illuminateswhenengineair cleanerelement(s)are full of debris. If illuminated, clean or replaceelement(s)immediately.
u
28. ENGINESTARTAID LAMP
Page 3-3
