SECTION 10 - RECOMMENDED SERVICE PARTS STOCK FIGURE 10-1. RECOMMENDED SERVICE PARTS STOCK
ITEM
418
PART NUMBER
QTY
DESCRIPTION
Ref
Note: The following list will service one machine (built to current production per date on the front cover) with emergency repair parts which can be installed in the field. Parts from the list should be replaced when inventory is depleted to keep service parts stock supplied. For further information, contact your JLG dealer or the JLG Industries Parts Department.
7024885
Ref 1
70002386 70005219
1 1
Coil Coil
70003788 70004871
1 1
Coil Coil
1001212415 1001129555
1 1
Controller Assembly (Drive and Steer) Controller Assembly (Lift and Swing)
70002838 70003614
1 1
Fill Cap Assembly (Includes Cap, Chain & Fill Basket) Filter Kit (Includes Hydraulic Element, Breather Element & Gasket)
3740067 3740140
1 1
Relay Relay
2860030 4360328
1 1
Key, Replacement Switch, Toggle
4360387 4360475
1 1
Switch, Push Button Switch, Emergency Stop
4360476 4360407
1 1
Switch, Contact Block Switch, Potentiometer
1001155045 1001159256
1 1
Switch, Toggle Switch, Toggle
1001161709
1 Ref
Switch, Toggle VARIABLE PARTS
1001181045 70003783
1 12
Breaker, 30mA/16Amp (CE Spec) Element, Air Cleaner (Deutz 2.9L4 and Deutz 2.3L3 Engines)
7016331 7020023
12 12
Filter, Oil (Deutz Engines) Filter, Fuel (Deutz 2.3L3 Engines)
70003463 8229242
12 1
Filter, Fuel - RME Resistant (Deutz 2.3L3 Engines) Fuse - 5Amp
8229244 2940074
1 1
Fuse - 15Amp Latch (Machines with Gate)
1001170094 1001118412
1 1
Module, Ground Control Module, Platform Control
1600387 1001119176
1 1
Module, LSS Control Switch, Limit (Drive Orientation)
1001137673
1
Switch, SkyGuard Assembly
REV
STANDARD PARTS Coil
520AJ
3121666
