OPERATING CONTROLS AND PROCEDURES
RT540E OPERATOR MANUAL
Figure 3-14 Item Numbers Item
3-30
Description
1
Transmission Temperature
2
Fuel Level
3
Battery Voltage
4
Engine Speed (Tachometer)
5
Engine Coolant Temperature
6
Diesel Exhaust Fluid (Optional)
7
Direction/Gear Number
8
Engine Warm-up Indicator (Wait-to-start)
9
Park Brake
10
Emergency Stop
11
Marker/Position/Side Light
12
Rear Wheels Not Centered
13
Four-Wheel Drive Indicator
14
Differential Lock Indicator (Optional)
15
Cold Temperature Warning (Optional)
16
Engine Stop
17
Engine Warning Indicator
18
Hydraulic Oil Temperature
19
Low Brake Pressure
20
System Fault
21
Boom Angle Too Low (Optional)
22
Third Wrap Indicator (Optional)
23
Low Steering Pressure (Optional)
24
Regen Needed (Optional)
25
Regen Inhibited (Optional)
26
High Exhaust Temperature (Optional)
27
Work Range Limiter Indicator (Optional)
28
Active Screen Indicator
29
Alerts Area
30
Status Bar
31
Status Area
