OPERATING CONTROLS AND PROCEDURES CRANE CONTROL SYSTEM (CCS)
RT540E OPERATOR MANUAL Item
The RT540E is equipped with the electronic CCS (Crane Control System). CCS includes a control unit in the cab and several control units (MWSCM and MWCCM) distributed over the superstructure and carrier.
Crane Control System (CCS) Display
Description
9
Anti Two-Block Indicator
10
Swing Brake Engaged Indicator
11
Brightness Sensor
12
Internal Temperature Warning Indicator
13
Turntable Pin Swing Lock Control
Menu Control 7 1 8
5
4
11 12
3
6
The Jog Dial operates the CCS identically to the buttons on the display console, providing easier access for the operator. Spinning the jog dial performs the same function as the navigation arrow buttons on the display console. The icon in the lower left corner of the display screen reminds the operator which display is being controlled by the jog dial at that time. The Screen Toggle Button (4) (Figure 3-13) is used to switch screens. The tab button can also be used to temporarily silence audible alarms. The functionality of the other buttons is different depending on the area, screen and menu.
2 5
4
11 12
3
2 1
9 6
10 3
13
C9521
5
FIGURE 3-12
FIGURE 3-13
Figure 3-12 Item Numbers Item
3-28
4
6
Figure 3-13 Item Numbers
Description
1
Rated Capacity Limiter (RCL) Display
2
CCS Operation Display
3
USB Diagnostic Connector
4
Escape Button
5
Tab Button
6
Menu Button
7
RCL Shutdown Warning Indicator
8
RCL Early Warning Indicator
Item
Description
1
Escape Button
2
Tab Button
3
Menu Button
4
Screen Toggle Button
5
Jog Dial (Rotate dial to move cursor)
6
OK/Enter Button (Press Jog Dial to select)
Published 01-15-2016, Control # 526-01
