OPERATING CONTROLS AND PROCEDURES
RT540E OPERATOR MANUAL
Set the Boom Turn jog dial clockwise to set boom, including aux nose and reeving options.
NOTE:
If no jib configuration is chosen for the boom, the following selection will be for reeving.
Hoist Selection Turn jog dial clockwise to select between the main and optional auxiliary hoists.
Set the Jib Length (if installed) Turn jog dial clockwise and select to determine and choose the length of the jib, including inserts.
Set the Jib Angle (if installed) Turn jog dial clockwise to program the jib angle after the length is selected.
