Table 3: Status and Maintenance Screens Display Mode
Description Dual Gauge Display
D
B
A
H
G
F
A.
Fuel level.
B.
Fuel level amber warning region. Indicates low fuel level.
C.
Fuel level red stop region. Indicates almost empty fuel tank.
D.
Diesel Exhaust Fluid (DEF) level.
E.
Accumulated operation time.
NOTE:Operation time is displayed in hours, and accumulates when the engine is running.
DEF
F.
Engine coolant temperature.
G. Engine coolant temperature amber warning region. Indicates elevated coolant temperature (above 212°F/100°C).
50% %
H.
Engine coolant temperature red stop warning region. Indicates serious coolant overheating condition (above 220°F/104°C).
IMPORTANT: Running the engine in an overheated condition can damage the engine.
123.4
I.
E
C
I
Allows a selection between several parameters. Press the top/bottom of navigation rocker button (A, Fig. 5) to switch between parameters: • Coolant temperature. • Battery voltage. • Engine power. • Accumulated operation time. • Engine crankshaft revolutions per minute. • Engine oil pressure.
DEF Quad Gauge Display
n/min
0 RPM
123.4 Hrs T
12.3 V
38
90 °F
Displays four different status parameters simultaneously. To change the displayed parameters, press and hold the ok button (E, Fig. 5) until orange bar (T) displays. Press the left/right side of navigation rocker button (A, Fig. 5) to select the parameter and press the top/bottom of navigation rocker button to change the selected parameter. Press the ok button again to dismiss orange bar (T).
50950233/G0221
