Operating bale twister
DANGER! Risk of fatal injury. If bale twister falls accidentally, this can cause serious injury.
P
☞ There must be no one in bale twister swivel area when it is triggered by control box.
O
8
• Press emergency stop switch to clamp wrapper and make it safe. DANGER! Damage to bale twister.
☞ Do not transport wrapping baler when bale twister is not set in safety position. – Stop tractor engine. – Remove ignition key. 9
(Fig. 6, 7, 8, 9)
Release of levers Q
– Remove spring clips (P) to release levers (N). – Slide right and left levers (N) away from pins of right (Q) and left (R) holders and from hinge pins (C). (Fig. 10, 11) P
C
N P 10 R
N P C P
0299 436.2 - BA VB - Rollant 255 Uniwrap
11
87
